Parts, manuals and support for BCZ260TS
All the support you need for BCZ260TS. Manuals, spare parts, guides, how-to’s, and more.
Choose article number
To show you the right support, choose an article number from this list.
Support content
Manuals & Documents(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for RedMax BCZ260TS. For earlier versions, see link below to search all manuals & documents.
Specifications
Specifications
BCZ260TSArt no: 967 19 43‑02 | |
|---|---|
| Engine | BCZ260TS Art no: 967 19 43‑02 |
| Cylinder displacement | 1.55 cu.inch |
| Clutch engagement speed (±120) | 4,000 rpm |
| Electrode gap | 0.01 in |
| Fuel consumption | 450 g/kWh |
| Fuel tank volume | 22.32 fl oz |
| Idling speed | 3,000 rpm |
| Maximum rpm output shaft | 6,261 rpm |
| Output shaft power | 1.27 hp |
| Spark Plug | NGK BPMR8Y |
| Torque, max. | 1.24 Nm |
| Torque, max. at rpm | 7,000 rpm |
| Product data | |
| Drive gear angle | 60 ° |
| Emission | |
| Exhaust emissions (CO average) CARB | 354.3 g/kWh |
| Dimensions | |
| Weight (excl. cutting equipment) | 10.8 lbs |
